Why does the hot film of the hot film air flow meter not adhere to dust?
1. Introduction to Air Flow Meter The function of an air flow meter is to measure the amount of fresh air entering the engine intake manifold and the intake temperature. Based on this information, the ECU corrects the fuel injection amount, limits smoke, and controls the EGR opening.
2. Installation Position The sensor is installed on the engine intake pipe, at the rear end of the air filter. 3. Working Principle 3.1. The principle of an air flow meter The air flow sensor integrates some electronic components on a ceramic substrate. When the engine is working normally, it first heats the diaphragm, and when fresh air flows through the sensor, it takes away some of the heat. At this time, the ECU will control the Wheatstone bridge on the diaphragm to supplement the heat, which will cause changes in the electrical signal. When the signal is transmitted to the ECU, The ECU will calculate the intake air volume based on this change. 3.2. The principle of the air temperature sensor. The intake air temperature sensor is a resistor with a negative temperature coefficient. When the intake air temperature changes, the resistance value of the resistor will change, which will cause a change in the signal voltage at the ECU end. The ECU calculates the intake air temperature based on this change. 3.3. Determination of airflow direction: There are two temperature resistors at each end of the hot film of the air flow meter. When the airflow passes through the hot film, it will take away some heat, so the temperature at the front end of the hot film is lower than that at the rear end. The ECU determines the direction of the airflow based on
_600x400.jpg)
2. Detection of Air Flow Meter: Fault Codes Related to Air Flow Meter
2. What are the 5 lines of the air flow meter??
The five wires of the air flow meter: two are intake temperature wires: one is a live wire, one is a signal wire, and the other three are a live wire, one is a ground wire, and one is a signal wire.. An air flow meter is a device that converts the amount of air drawn in into an electrical signal. The advantages of an air flow meter are minimal pressure loss and a wide range of measurable flow rates. The ratio of the maximum flow rate to the minimum flow rate of an air flow meter is generally above 20:1, and it is suitable for a wide range of industrial pipe diameters, up to 3m. The output signal is linear with the measured flow rate, with high accuracy, and can measure the fluid flow rate of acid, alkali, salt solutions, water, sewage, corrosive liquids, as well as mud and slurry with conductivity ≥ 1 μ s/cm. But air flow meters cannot measure the flow of gas, steam, and purified water. Additional information: Classification of principles of air flow meters Blade type ai
